Slot Die Hotmelt Adhesive Coating Machine In Label

This slotdie hot melt adhesive coating machine is totally different from troditional technology, like solvent glue or water glue, solvent glue is bad for environment. Hot melt adhesive no solvent, solid content 100%, needn't dry, energy consumption less, equipment size small, price cheap than solvent equipment.

Please send your inquiry to joyhuang@simymachine.com

  • Item No.:

    SIMY-SDH
  • Lead Time:

    10 days
  • Payment:

    Credit Card, Paypal, T/T , Western Union, LC
  • Warranty Period:

    1 year
  • Customizable:

    Yes
  • Product Detail

Slot Die Hotmelt Adhesive Coating Machine In Label

Equipment Introduction

1. Main engine with glue pump track together, operate manual control alone too.

2. Use import intelligent PID temperature system, stabile temperature and error in 1 °c.

3. Multi rool enlarge cooling installation, enlarge base material use range, improve produce speed.

4. Independent research and development of high precision metering pump with high precision alloy steel die, realized the high quality coating effect.

Application

1. Industry adhesive tape(cleaning adhesive tape, Kraft adhesive tape, masking tape, aluminum foil, fiber tape, duct tape, foam tape etc.)

2. Medical protect tape(infusion tape, band-aid, wound tape, protect bandages etc.)

3. Shoes material, clothing accessories(EVA shoes material, hot glue tape film, duct tape etc.)

Parameters

Max temperature

230°c

Coating speed

2-200m/min

Coating quantity

5-200g/m2

Coating width

200-2500mm

Unwind device

2 sets

Unwind Dia.

1000mm

Rewind device

1 set(double position)

Rewind Dia.

1000mm

Subtense device

2 sets

Length

4800mm

Width

2400mm

Hight

1500mm

Installed capacity

3 phase 4 wire 25kw
