Carton Die Cutting Pizza Box Machine For Corrugated Cardboard Paper Plate Punching
Product introduce
Suitable for laminating and punching various roll and sheet materials. Using a computer servo CNC system for material pulling and feeding, it can be used for full break, half break punching, waste disposal, high accuracy, low noise, fast speed, and has anti scratch function. It can perform secondary die-cutting and stamping, and is widely used in the electronics and printing industries. Customizable secondary positioning die cutting function according to customer needs.
Specification
|
Dual servo standard die-cutter |
||||
|
Item |
Order number |
Project name |
Unit |
The number of content |
|
Machine configuration and parameters |
1 |
Feed width |
MM |
310 |
|
2 |
Maximum mode cut area |
MM |
300*270 |
|
|
3 |
Maximum running speed |
PCS/H |
24000 |
|
|
4 |
Rated running speed |
PCS/H |
1508 24000 |
|
|
5 |
Module stroke |
MM |
20 |
|
|
6 |
Schedule adjustment |
MM |
7 |
|
|
7 |
Pressure flatness |
MM |
±0.01 |
|
|
8 |
Material pulling accuracy |
MM |
±0.1 |
|
|
9 |
Outline dimension |
MM |
2000*1200*1900 |
|
|
10 |
Machine net weight |
Kg |
1550 |
|
|
11 |
Upper template size (thick) |
MM |
350*270*33.6 |
|
|
12 |
Upper Template Size (thin) |
MM |
350*270*18 |
|
|
13 |
Lower templateSize |
MM |
420.5*270*18 |
|
|
14 |
Aggregate capacity |
KW |
5 |
|
|
17 |
Module maximum pressure |
T |
5 |
|
|
15 |
lubricating system |
|
Automatic cycle oil supply |
|
|
16 |
Applicable to knife mode |
|
Wood knife mold, rubber board mold, rot Erosion die, engraving die, steel die |
|
