Tubular Sterilizer Milk Beverage Beer
Product Introduce
This equipment is suitable for pasteurization and high-temperature sterilization of non corrosive liquids in stainless pans, such as dairy products, alcoholic beverages, milk, fresh milk, beverages, etc. According to the user's process, the equipment should meet the requirements of simultaneous heating, insulation, heat recovery, and cooling of materials.
The precise control system automatically controls and records the sterilization temperature of materials, and automatically returns unqualified materials to ensure thorough sterilization.
Corrugated tube is used for heat exchange tube, with high heat transfer coefficient. Its combination of double head quick installation is convenient for maintenance.
Specification
| Name/unit/models | SIMY-1 | SIMY-2 | SIMY-3 | SIMY-5 |
| Production capacity(t/h) | 1 | 2 | 3 | 5 |
| Material inlet temperature(℃) | 5 | 5 | 5 | 5 |
| Sterilization temperature(℃) | 85-135 | 85-135 | 85-135 | 85-135 |
| Material interface size(mm) | ∮38 | ∮38 | ∮38 | ∮51 |
| Steam pressure(mpa) | 0.4 | 0.4 | 0.4 | 0.4 |
| Compressed air pressure(mpa) | 0.6 | 0.6 | 0.6 | 0.6 |
| Overall dimensions(mm) | 3500X1600X1800 | 4500X2000X1900 | 4500X2500X2000 | 5000X2000X2000 |
