Polyethylene Wax Extruder PE Wax Extrude
Equipment introduction
In the past pe wax production, usually using polymerization kettle pyrolysis process, this process has the following shortcomings: process discontinuity, poor safety, low wax rate, wax rate below 85%, labor intensity, poor environmental protection, etc.
After years of practice, we have successfully developed the above problems, extrusion cracking process equipment, the equipment advanced technology, good production continuity, high wax rate, up to 93%- 96%, high safety, environmental protection, low production cost, durable, and technology is more and more mature, and continuous improvement, perfect.
The production line is a special equipment for the production of polyethylene wax, which is composed of the main engine of the extruder cooling tank, diesel recovery tank and pipeline valve, etc. The production process of the production line is the wax of high coupling high temperature polyethylene raw material by extruder high temperature extrusion. pe wax is an important additive in plastics, dyes, coatings and other industries. In the processing of modified masterbatch of plastics, such as color masterbatch and filling masterbatch, it is widely used as an excellent dispersant because of its low cost.
Specification
Screw diameter |
140 mm |
Maximum extrusion diameter |
1 mm |
Productive capacity |
100-200 Kg/h |
Positioning accuracy |
1 mm |
Overall dimension |
5300×140 mm |
Motor power |
45 kw |
Main engine screw diameter |
φ140, diameter ratio1:35 |
Screw and barrel materials |
38crmoala;Nitriding treatment, hardness hv900-1100, depth of 0.5-0.7 |
Yield |
φ140:100-190kg/h, 3-4 T/day; φ160:150-250kg/h |
