Extrusion flat coating machine
Lab Extrusion Flat Coating Machine Lab Extrusion Flat Coating Machine Lab Extrusion Flat Coating Machine

Lab Extrusion Flat Coating Machine

The extrusion flat coating machine is a device applied to the surface coating of sheet shaped substrates, which uses a narrow slot extrusion method for coating.

Please send your inquiry to joyhuang@simymachine.com

  • Item No.:

    SIMY-100

  • Lead Time:

    10 days

  • Payment:

    Credit Card, Paypal, T/T , Western Union, LC

  • Warranty Period:

    1 year

  • Customizable:

    Yes
  • Product Detail

Lab Extrusion Flat Coating Machine


Product description

The extrusion flat coating machine is a device used for coating the surface of sheet shaped substrates, using a narrow slot extrusion method for coating. This equipment mainly consists of extrusion molds, coating platforms, feeding systems, and control systems, mainly used for laboratory research and development, and can work in glove boxes. This equipment is mainly used for surface coating of chip substrates in the fields of lithium battery substrates, OLEDs, solar photovoltaic films, and polymer conductive films.


Specification

Substrate dimension

L150*W130mm

Coating size

Max.L100*W100mm（Standard）

Lip height

0～5mm，adjustable

Adjusting accuracy

Micrometer adjustment, display accuracy 1um

Machine speed

Extrusion coating head movement speed 0.5-30mm/s

Substrate thickness

Max：5mm

Substrate temperature

Max：120℃（Heating time is more than half an hour）

Injection Capacity

Standard 10ml, 20ml, 30ml stainless steel syringe

Feed rate

0.05-5mm/s（Cylinder piston speed）

LxWxH

L440*W340*H330mm

Weight

About 20Kg
