Food Paper Box Wax Machine Corrugated Board Wax Coating Machine
Product introduce
1.This machine is mainly used in food and packaging industry's packaging paper wax coating, so that papers can be moisture proof and waterproof, such as hamburge paper, candy paper, soap paper and carton packaging kraft paper coated wax
2. Wax one side of paper or two sides of paper
3. Wax coating weight can be controled 4-5 gsm for one side
4.circle water cooling system
Specification
|
Specification |
SIMY-L1200 |
|
Max.Web Width |
1220mm |
|
Max.Waxing Coating Width |
1200mm |
|
Max.Unwinder Diameter |
1524mm |
|
Max.Rewinder Diameter |
1524mm |
|
Max Wax Coating speed |
150m/min |
|
Unwinder Power |
15KW |
|
Rewinder Power |
15KW |
|
Cooling Power |
10-15P |
|
Wax Melting Power |
Main Wax Melting Power: 9KW |
|
Auxiliary Wax Melting Power: 12KW |
|
|
Power Requirement |
380V 3PH 50Hz |
|
Substrate |
28-300gsm paper |
